NextPhase™ Low Loss Cables

- General purpose system interconnects
- Low insertion loss
- Long lengths available
- DC-40 GHz

The NextPhase series of high performance interconnect cables are designed for end users who need exceptional insertion loss performance at a reasonable cost. These low density dielectric cables are available in a variety of suitable diameters which can be selected based on the end item loss and frequency requirements. The diameter varieties also enable the design engineer to accommodate a wide range of design requirements in terms of bend radii, weight and power performance. Each cable features triple shield construction to eliminate interference from adjacent signals and these high performance assemblies are available with a wide range of connectors offering excellent VSWR characteristics.
