性能及特点

稳幅稳相      Phase and amplitude stable with flexure

耐压耐磨      Crush and Abrasion resistance

精确测量      Accurate measurements

长寿命        Long service life

高柔韧性      High degree of flexibility and low spring-back

仪器端口

Test Port

电缆端口1

Connector 1

电缆端口2

Connector 2

频率

Frequency

驻波比

VSWR

插损

IL( 630mm长度，其他长度可以定制）

幅度稳定度

Amplitude

Stability

相位稳定度

 Phase Stability

Type N

female

Type N

male

Type N male

18GHz

1.20:1 max

<1.5dB

<±0.05dB

<±2.0°

Type N female

NMD3.5mm male

3.5mm female

NMD3.5mm

male

NMD3.5mm

female

NMD3.5mm male

26.5GHz

1.25:1 max

<1.8dB

<±2.5°

3.5mm female

Type N male

18GHz

1.20:1 max

<1.5dB

<±2.0°

Type N female

NMD2.92mm

male

NMD2.92mm

female

NMD2.92mm male

40GHz

1.30:1 max

<2.8dB

<±3.0°

2.92mm female

NMD2.4mm male

2.4mm female

NMD2.4mm

male

NMD2.4mm

female

NMD2.4mm male

50GHz

1.35:1 max

<3.2dB

<±3.5°

2.4mm female

NMD2.92mm male

40GHz

1.30:1 max

<2.8dB

<±3.0°

2.92mm female

NMD1.85mm

male

NMD1.85mm

female

NMD1.85mm male

67GHz

1.50:1 max

<5.8dB

<±6.5°

1.85mm female
